Clamshell Spring Pin Socket for Power Transistor Constructed with stamped spring pin technology rated for 23GHz bandwidth with operating temperature range of -55C to +180C. Current capacity is 4 Amps with self-inductance of 0.93 nH and capacitance of 0.097 pF. With lever operation, it is easy to swap device and characterize.

March 2023

Clamshell Production Test Socket for BGA35 Socket and Test your 4.2x3.8mm BGA device using extreme temperature socket

February 2023

Ironwood Electronics recently introduced a new Stamped spring pin socket addressing high performance requirements for testing BGA35 - CBT-BGA-7525. The contactor is a stamped spring pin with 8 gram actuation force per ball and cycle life of 75,000 insertions. The

Grypper socket for LPDDR5 SDRAM Chip size socket connects LPDDR5 to system PCB with minimal signal loss. Supported device size is 14x14mm, 21x21 array, 0.65mm pitch BGA 441. Once the socket is soldered down to PCB, device can be simply plugged into it. This Grypper socket has excellent electrical performance of – 1dB insertion loss greater than 25.0 GHz. Force required to insert a device is only 25 grams / contact.

January 2023

Elastomer socket for BGA1365 The SM-BGA socket is constructed with high performance (>40GHz bandwidth) and low inductance elastomer contactor. The temperature range is -55 C to +150 C. The pin self-inductance is 0.21 nH. Capacitance to ground is 0.15 pF. Current capacity is 4 amps per pin.

December 2022

Elastomer Socket for BGA324 with 23 Watt Power Dissipation Elastomer used in the socket, as a contactor between the IC package and the circuit board, is a low resistance (less than 0.05ohms) connector. The elastomer consists of a fine pitch matrix of gold plated wires in a soft insulating sheet of silicone rubber. The sockets have a precision design, which guides the IC to the exact position for connection of each ball and uses an aluminum heat sink to provide compressive force.

November 2022
